| Application |
Assembly |
| Low Pressure Air, Fuel, Lube, and Oil Lines, Pressure determined by tube material and hardness. |
1- Lubricate insert. |
| Advantages: Easy assembly. No clamps needed!! |
2- Hold hose at angle as shown & push on and up over first barb. |
| Specification |
3. Continue to push straight on until hose is seated under protective plastic cap. Keep hands back from hose end area so that hose can expand. |
| 1.Air (inside + outside) up to max. + 70° C |
Disassemble |
| 2. Oil-enriched compressor air |
1. Cut the hose longitudinally along a line at a slight angle from the centre line of the hose. (Be careful not to nick barbs when cutting hose) |
| 3. Water (inside + outside) up to max. + 82° C |
2. Disengage the fitting from the hose. |
| 4. Coolants,Antifreeze,Lubricant oil,Fluids with a mineral oil base |
